ARRI ALEXA MINI LF
The ARRI ALEXA MINI LF is a compact and lightweight digital cinema camera that combines the large format sensor of the ALEXA LF with the compact form factor of the ALEXA MINI, offering exceptional image quality and versatility for professional filmmakers.
Add items
Scroll
ARRI
ARRI ALEXA MINI LF
The ARRI ALEXA MINI LF is a compact and lightweight digital cinema camera that combines the large format sensor of the ALEXA LF with the compact form factor of the ALEXA MINI, offering exceptional image quality and versatility for professional filmmakers.
Add items
Technical Data
| Sensor Type | Large Format ARRI ALEV III (A2X) CMOS sensor with Bayer pattern color filter array |
|---|---|
| Sensor Size | 36.70 x 25.54 mm / 1.444 x 1.005" |
| Image circle 44.71 mm / 1.760" | |
| Sensor Resolution | 4448 x 3096 |
| Dynamic Range | 14+ stops |
| Maximum Frame Rate | up to 90 fps |
| Recording Formats | ARRIRAW/Apple ProRes 4444 XQ/Apple ProRes 4444 |
| Apple ProRes 422 HQ | |
| Recording Media | Codex Compact Drive 1TB/2TB |
| Lens Mount options | LPL/PL/EF |
| Integrated Filters | ND filters 0.6, 1.2, 1.8; Fixed optical low pass, UV, IR filter |
| ISO Range | 160-3200 |
| Color Output | Rec 709, Rec 2020, Log C, |
| Custom Look (ARRI Look File ALF-2) | |
| Viewfinder | Multi Viewfinder MVF-2 with 4" flip-out touchscreen monitor. OLED viewfinder display; |
| LCD flip-out monitor | |
| Interfaces | 1x VF custom CoaXPress |
| 2x 6G SDI (BNC) | |
| 1x LBUS (LEMO 4-pin) for lens motors, daisy chainable | |
| 1x LEMO 5pin LTC Timecode In/Out | |
| 1x LEMO 10pin Ethernet for remote control and service | |
| 1x BNC SYNC IN | |
| 1x LEMO 7pin EXT multi purpose accessory interface w. RS pin and 24V power output | |
| 1x LEMO 4pin LBUS (on lens mount) for lens motors, daisy chainable | |
| 1x USB 2.0 in media bay (for user setups, look files etc) | |
| 1x Fischer 3pin 24V RS | |
| 1x LEMO 2pin 12V | |
| 3,5mm stereo headphone jack (on MVF-2) | |
| Audio Input | 1x LEMO 6pin balanced stereo line in with 12V power output |
| Two built-in microphones for scratch audio | |
| Power Input | 1x LEMO 8pin (11-34 V DC) |
| Weight | ∼2.6 kg / ∼5.7 lbs |
| Dimensions | 140 x 143 x 188 mm / 5.5 x 5.6 x 7.4" |
Included products
- 3 Codex compact drives 1TB
- Codex compact drive reader (USB-C)
- MVF-2 Viewfinder
- Viewfinder cable 0.5m
- Viewfinder cable 0.35m
- Viewfinder extension bracket VEB-3
- PL to LPL Adapter
- Power cable straight KC-50 2m
- V-Mount Power Splitting Box MKII
- ARRI Studio cage set
- Rods 19mm (9” 24cm) BT Drumstick
- Rods 15mm (9” 24cm) BT Drumstick
